Ubiquiti airMAX NanoStation M5 (NSM5) 5GHz Outdoor
KShs 16,500
- 5 GHz Wireless
- 802.11a/n
- 2 × 2 MIMO
- airMAX Technology
- Up to 150+ Mbps Throughput
- 14.6–16.1 dBi Integrated Antenna
- Dual-Linear Polarization
- 2 × 10/100 Ethernet Ports
- Passive PoE Powered
- 24V, 0.5A PoE Adapter
- 64MB DDR2 RAM
- 8MB Flash Storage
Description
Technical Specifications
| Feature | Specification |
| Model Code | NSM5 |
| Operating Frequency | 5 GHz (5170–5875 MHz) |
| Processor & Memory | Atheros MIPS 24KC, 400 MHz | 32 MB SDRAM, 8 MB Flash |
| Networking Interfaces | 2x 10/100 Mbps Ethernet Ports |
| Antenna Gain | 16 dBi Dual-Polarization Panel Antenna |
| Cross-Pol Isolation | 22 dB Minimum |
| Beamwidth | 43° (Horizontal) / 45° (Vertical) / 15° (Elevation) |
| Max TX Power | 27 dBm |
| Power Method | 24V, 0.5A Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| PoE Passthrough | Software-Enabled Secondary Port (24V Passive) |
| Max Power Consumption | 8 W |
| Dimensions & Weight | 294 x 80 x 31 mm (11.6 x 3.1 x 1.2″) | 400 g (14.1 oz) |
| Mounting | Pole Mounting Kit Included |
